Reabating Bits
Bearing Size: D-13 x B-5 x Thick-4
Machine: Manual Router Machine, CNC Router Machine
Application: Solid Wood, Particle Board, MDF.
Note: Custom Size Accepted
Depth: 12mm.
| Code No. | Thick (mm) | Depth (mm) | Teeth | Shank (mm) |
|---|---|---|---|---|
| 126AA | 3 | 12 | 4 | 8 |
| 126A | 4 | 12 | 4 | 8 |
| 126 | 6 | 12 | 4 | 8 |
| 127 | 8 | 12 | 4 | 8 |
| 127A | 9 | 12 | 4 | 8 |
| 128 | 10 | 12 | 4 | 8 |
| 129 | 12 | 12 | 4 | 8 |
| 130 | 15 | 12 | 4 | 8 |
| 131 | 19 | 12 | 4 | 8 |
| 131D | 19 | 12 | 4 | 12 |
| 131A | 25 | 12 | 4 | 8 |
| 131E | 25 | 12 | 4 | 12 |
| 131B | 32 | 12 | 4 | 12 |
| 131C | 38 | 12 | 4 | 12 |
Depth: 15mm.
| Code No. | Thick (mm) | Depth (mm) | Teeth | Shank (mm) |
|---|---|---|---|---|
| 401A | 4 | 15 | 4 | 8 |
| 401B | 4 | 15 | 4 | 12 |
| 402A | 6 | 15 | 4 | 8 |
| 402B | 6 | 15 | 4 | 12 |
| 403A | 8 | 15 | 4 | 8 |
| 403B | 8 | 15 | 4 | 12 |
| 404A | 9 | 15 | 4 | 8 |
| 404B | 9 | 15 | 4 | 12 |
| 405A | 10 | 15 | 4 | 8 |
| 405B | 10 | 15 | 4 | 12 |
| 406A | 12 | 15 | 4 | 8 |
| 406B | 12 | 15 | 4 | 12 |
Depth: 19mm.
| Code No. | Thick (mm) | Depth (mm) | Teeth | Shank (mm) |
|---|---|---|---|---|
| 401C | 4 | 19 | 4 | 8 |
| 401D | 4 | 19 | 4 | 12 |
| 402C | 6 | 19 | 4 | 8 |
| 402D | 6 | 19 | 4 | 12 |
| 403C | 8 | 19 | 4 | 8 |
| 403D | 8 | 19 | 4 | 12 |
| 404C | 9 | 19 | 4 | 8 |
| 404D | 9 | 19 | 4 | 12 |
| 405C | 10 | 19 | 4 | 8 |
| 405D | 10 | 19 | 4 | 12 |
| 406C | 12 | 19 | 4 | 8 |
| 406D | 12 | 19 | 4 | 12 |
Depth: 25mm.
| Code No. | Thick (mm) | Depth (mm) | Teeth | Shank (mm) |
|---|---|---|---|---|
| 402E | 6 | 25 | 4 | 8 |
| 402F | 6 | 25 | 4 | 12 |
| 403E | 8 | 25 | 4 | 8 |
| 403F | 8 | 25 | 4 | 12 |
| 404E | 9 | 25 | 4 | 8 |
| 404F | 9 | 25 | 4 | 12 |
| 405E | 10 | 25 | 4 | 8 |
| 405F | 10 | 25 | 4 | 12 |
| 406E | 12 | 25 | 4 | 8 |
| 406F | 12 | 25 | 4 | 12 |
